Description
Dell 290W Power Supply RVTHD / N0KPM | OptiPlex 3020 / 7020 / 9020 MT, PowerEdge T20 / T30 / T130, Precision T1700 / T3620 (8 + 4 Pin)
Key Features
- New original Dell 290W power supply for OptiPlex 3020 / 7020 / 9020 MT, Precision T1700 / T3620, and PowerEdge T20 / T30 / T130 systems
- Dell part numbers: RVTHD / N0KPM / KPRG9 / HYV3H — same physical unit, interchangeable DPN across platforms
- PSU model numbers: H290AM-00 / L290AM-00 / AC290AM-00 / PS-3291-1DF / D290A001L / H290EM-00
- Dimensions: 150 x 140 x 86 mm – Dell MT standard form factor
- Connector layout: 8-Pin + 4-Pin (8+4P) – Dell MT proprietary connector
- 290W stable output for Dell MT tower desktop, workstation and server platforms
- Built-in OVP / OCP / SCP protection
- Not interchangeable with SFF variants – MT chassis specific
Technical Specifications
| Brand | Dell |
| Condition | New Original (Genuine Dell) |
| Dell PN | RVTHD / N0KPM / KPRG9 / HYV3H |
| PSU Model | H290AM-00 / L290AM-00 / AC290AM-00 / PS-3291-1DF / D290A001L / H290EM-00 |
| Wattage | 290W MAX |
| Input Voltage | 100-240V AC, 50-60Hz |
| Output | 290W MAX continuous output |
| Form Factor | Dell MT Tower, Non-Hot-Swap, Proprietary (150 x 140 x 86 mm) |
| Connector Type | 8-Pin + 4-Pin (8+4P) |
| Hot Plug | No |
| Protection | OVP / OCP / SCP |
Compatible Models
Dell OptiPlex Series (Haswell MT):
- Dell OptiPlex 3020 / 7020 / 9020 MT
Dell Precision / PowerEdge:
- Dell Precision T1700 MT
- Dell Precision T3620
- Dell PowerEdge T20
- Dell PowerEdge T30
- Dell PowerEdge T130
!
Disclaimer
Always verify the part number / model number on your existing PSU label before purchasing.
If you are unsure which model is suitable, chat with the NJ Bravo team before ordering. We will help you check the part number, connector, and compatibility.
Package Contents
- 1x Dell 290W Power Supply RVTHD / N0KPM (New Original)
Warranty
- 90-day replacement warranty
- Covers manufacturing defects; physical damage and improper installation not included
Additional Notes
- 8+4P Dell MT proprietary connector – verify connector layout matches your system before ordering.
- 150 x 140 x 86 mm form factor is Dell MT standard – not compatible with Dell SFF chassis.
- Verify Dell DP/N matches RVTHD or N0KPM on existing PSU label.
- New original unit – genuine factory Dell unit, not refurbished or aftermarket.
