Description
Dell 275W Power Supply FDT8H / R8JX0 | OptiPlex 3010 / 7010 / 9010 MT, Precision T1600 / T1650 MT (24 + 4 Pin + SATA x4)
Key Features
- New original Dell 275W power supply for OptiPlex 3010 / 7010 / 9010 MT and Precision T1600 / T1650
- Dell part numbers: FDT8H / R8JX0 / NFRTK / 61J2N / D3PMV
- PSU model numbers: AC275AM-00 / HU275AM-00 / PCB013
- Dimensions: 150 x 140 x 86 mm – Dell MT standard form factor
- Connector layout: 24-Pin + 4-Pin CPU + SATA x4 – standard ATX-style Dell MT connector
- 275W for Sandy Bridge / Ivy Bridge OptiPlex MT platform
- Built-in OVP / OCP / SCP protection
- 24-pin ATX connector – different from newer 3020/7020/9020 MT variants
Technical Specifications
| Brand | Dell |
| Condition | New Original (Genuine Dell) |
| Dell PN | FDT8H / R8JX0 / NFRTK / 61J2N / D3PMV |
| PSU Model | AC275AM-00 / HU275AM-00 / PCB013 |
| Wattage | 275W MAX |
| Input Voltage | 100-240V AC, 50-60Hz |
| Output | 275W MAX continuous output |
| Form Factor | Dell MT Standard (150 x 140 x 86 mm) |
| Connector Type | 24-Pin + 4-Pin CPU + SATA x4 (24+4P+SATAx4) |
| Hot Plug | No |
| Protection | OVP / OCP / SCP |
Compatible Models
Dell OptiPlex Series (Sandy/Ivy Bridge MT):
- Dell OptiPlex 3010 / 7010 / 9010 MT
Dell Precision:
- Dell Precision T1600 / T1650 MT
!
Disclaimer
Always verify the part number / model number on your existing PSU label before purchasing.
If you are unsure which model is suitable, chat with the NJ Bravo team before ordering. We will help you check the part number, connector, and compatibility.
Package Contents
- 1x Dell 275W Power Supply FDT8H / R8JX0 (New Original)
Warranty
- 90-day replacement warranty
- Covers manufacturing defects; physical damage and improper installation not included
Additional Notes
- 24-pin ATX connector layout – different from newer Haswell 3020/7020 MT (those use 8+4P or different layout).
- 4x SATA connectors – good for systems with multiple drives.
- Verify Dell DP/N matches FDT8H or R8JX0 on existing PSU label.
- New original unit – genuine factory Dell unit, not refurbished or aftermarket.
