Description
NP330 Single-Port USB Network Print Server
Source Details
Compact single-port USB network print server for home and office LAN printing over wired Ethernet.
Key Features
- New NP330 compact single-port USB network print server for home and office LAN printing
- One USB 2.0 Type-A host port (USB0) — connects a USB printer directly to the local network
- 1x RJ45 Ethernet port — 10/100Mbps wired LAN connectivity
- Supports TCP/IP printing protocol (LPR/LPD); default print port 9100 (user-configurable)
- ARM9 300 MHz processor, 128 MB Flash for reliable multi-user print service
- Type-C USB port for power and configuration; Windows config tool included
- TF card expansion slot — local storage up to 256 GB
- Web-based browser management; DHCP and static IP supported
- Compact and lightweight design, 5V DC powered
Technical Specifications
| Brand | NP Series |
|---|---|
| Model | NP330 |
| Condition | New |
| USB Port | 1x USB 2.0 Type-A Host (USB0) |
| USB Config Port | 1x USB Type-C (power & configuration) |
| Network Port | 1x RJ45 Ethernet — 10/100Mbps |
| Wireless | None (wired LAN only) |
| Print Protocol | TCP/IP, LPR/LPD |
| Default Print Port | 9100 (configurable: 9100–65535) |
| Processor | ARM9 300 MHz |
| Flash Memory | 128 MB |
| TF Card Slot | Yes — up to 256 GB |
| Power | 5V DC |
| OS Support | Windows XP and above |
!
Disclaimer
Always verify your printer’s connection type and network requirements before ordering.
If you are unsure which model is suitable, chat with the NJ Bravo team before ordering. We will help you check the part number, connector, and compatibility.
Package Contents
- 1x NP330 USB Network Print Server (New)
- 1x USB Type-C Cable
- 1x Quick Start Guide
Warranty
- 3-month replacement warranty
- Covers manufacturing defects; physical damage and improper installation not covered
Additional Notes
- Wired Ethernet only — the NP330 has no Wi-Fi; a wired connection to a router or switch is required.
- Requires configuration before first use — not plug-and-play; connect via USB Type-C to a Windows PC using the config tool, or configure via browser once IP is assigned.
- Assign a static IP address to avoid connectivity issues from DHCP lease changes.
- Supports only one USB printer at a time (USB0); for 3-printer support, consider NP332NW (Wi-Fi) or NP332NWB (Wi-Fi + Bluetooth).
