Description
Lenovo 280W Power Supply PCB033 | ThinkCentre H530 / M8400t / TS230 Tower (14 + 4 Pin) – AcBel
Key Features
- New original Lenovo / AcBel 280W tower power supply for ThinkCentre H530 / M8400t / TS230
- Model: PCB033 – AcBel OEM 14-pin Tower PSU for Lenovo
- Compatible FRU / PN: HK380-16FP / FSP280-40PA / HK280-23FP
- Lenovo proprietary 14-Pin main + 4-Pin CPU connector (14+4P) – ThinkCentre Tower proprietary
- Tower MT form factor (150 x 140 x 86 mm) – full-size tower chassis specific
- Stable 280W output for ThinkCentre Tower desktop workloads
- Built-in OVP / OCP / SCP protection
- AcBel OEM – same spec as factory Lenovo unit
Technical Specifications
| Brand | Lenovo OEM (AcBel) |
| Condition | New Original |
| Model Number | PCB033 |
| FRU / PN | HK380-16FP / FSP280-40PA / HK280-23FP / PCB033 |
| Wattage | 280W MAX |
| Input Voltage | 100-240V AC, 50-60Hz |
| Output | 280W MAX continuous output |
| Form Factor | Lenovo Tower MT (150 x 140 x 86 mm) |
| Connector Type | 14-Pin + 4-Pin CPU (14+4P) |
| Hot Plug | No |
| Protection | OVP / OCP / SCP |
Compatible Models
Lenovo ThinkCentre Tower / Server Series:
- Lenovo ThinkCentre H530 Tower
- Lenovo ThinkCentre M8400t Tower
- Lenovo ThinkServer TS230 Tower
!
Disclaimer
Always verify the part number / model number on your existing PSU label before purchasing.
If you are unsure which model is suitable, chat with the NJ Bravo team before ordering. We will help you check the part number, connector, and compatibility.
Package Contents
- 1x Lenovo 280W Power Supply PCB033 (New Original)
Warranty
- 90-day replacement warranty
- Covers manufacturing defects; physical damage and improper installation not included
Additional Notes
- 14-Pin proprietary connector – Tower MT specific. Different from TFX 10-pin or SFF 24-pin Lenovo families.
- 150 x 140 x 86 mm form factor – full tower chassis. NOT compatible with SFF or TFX chassis.
- Verify FRU/PN on existing PSU matches PCB033 or HK380-16FP before ordering.
- New original unit – not refurbished or aftermarket.
